Male and female tab plates bolt directly to truss frames using four B-CB1 carriage bolts. Once mounted, sections can be connected using a B-HB3 (¾" bolt) or a B-PIN (connector pin) for smooth, adjustable movement between dock sections.
Specifications:
Compatibility: Truss-style dock frames
Fasteners Required: (4) B-CB1 carriage bolts per hinge assembly
Connection Options: B-HB3 (¾" bolt) or B-PIN (connector pin)
Installation: Pre-punched alignment, no drilling necessary
Application: Floating and modular dock systems
The Hinge Assembly allows for easy connection of adjacent dock sections, providing secure flexibility between frames. Designed for use with truss-style dock frames, this system ensures quick installation and long-term structural reliability in floating dock applications.
